Brogan & Patricks Enhances Quality Processes with New Multisensor Measurement System


Brogan & Patrick is excited to announce a new addition to our company!  Brogan & Patrick Mfg. recently purchased and installed a brand new Vertex Multisensor Measurment System by Micro-Vu Corp.  This new technology provides speed and accuracy utilizing vision, touch and laser. The system has programmable optical zoom, 3x digital zoom and advanced LED lighting.  This Multisensor Measurement System provides point and click simplicity for edge detection, measurement data and tolerances.  The touch probe allows QC to reach tiny grooves, deep holes and difficult to reach locations.  The system allows for full reverse engineering capabilities and file storage.  The Vertex accepts DXF and IGES files for fast, easy inspection of existing programs.  With zoom range of 15x – 540x, magnification of components will be a breeze and we will be able to export to a JPG or BMP file.  The addition of the Vertex with its Hi-Res camera, advanced illumination, touch probe, and motorized programmable lens will allow us to quickly and accurately quality control the complex parts we supply to our customers.
